LDARC F411-B2 Brushed Drone Controller with ESC

An awesome flight experience packed into a TINY package! At only 3.7g, this flight controller/ESC offers 5A per channel and the capability of an F411 processor. The micro board is compatible with all brushed motors up to 1250 size and up to 5A per motor (peak current 8A). . Features: F411 FC + 4in1 ESC AIO Supports flip over after crash (reverse) Supports 1S (4.2V) LiPo battery input voltage >10A operating current with large NMOS transistors 5A operating current per channel, 8A max Supports PPM/SBUS/DSM/Other receivers Supports up to 4 brushed motors Specifications: Processor: F411 Target: Only use LDARC custom firmware (F411-B2-BF3.5.6-2021-03-29-a.hex), Scan QR code on the product packing box and download the firmware from the cloud driver. Input Voltage: 3.7-4.35V Mounting Dimensions: 25.5x25.5mm (M3) Weight: 3.7g Link to manual: https://15736572.s21i.faiusr.com/61/ABUIABA9GAAgqZvtiwYo2LzKhAM.pdf Package Contents: 1x LDARC F411-B2 Flight Controller AIO 1x Micro Losi Power Cable 1x Bushing Adapters for M2 Screws
